Type – John Deere 3029H, 57 HP (42 kW), 2100 RPM, 3 Cylinders, Turbo Charged, HPCR fuel injection system, Coolant cooled with overflow reservoir
Air Filter – Dry Type, Dual element
CleanPro™ :

1.Enhanced Cooling Efficiency :
The reversible fan helps in maintaining optimal engine operating temperature by reversing the airflow, especially in applications with excessive debris or when working in high-temperature conditions. This effectively prevents overheating and ensures efficient cooling.
2.Reduced Downtime :
By clearing debris from the radiator screen & front grill, the reversible fan minimizes the need for manual cleaning and reduces the risk of engine overheating or downtime due to debris blockage.
3.Improved Productivity :
Customers can experience increased operational efficiency and productivity as the reversible fan system helps prevent interruptions caused by overheating and debris build-up.
4.Extended Engine Life :
By maintaining optimal operating temperatures and preventing overheating, the reversible fan can contribute to prolonged engine life and reduced wear and tear on engine components.
5.Reversible fan :
Hood screen and radiator cleaning.

Clutch – Dual clutch, Dry clutch, EH clutch (optional)
Gear box – 12F + 4R (GearPro Speed)
12F + 12R (PowrReverser Speed)
9F + 3R (Creeper Speed)
Speed Options –GearPro Speed- 1.9 to 32.6 Kmph, PowerReverser Speed- 1.4 to 31.3 Kmph and Creeper Speed- 0.35 to 0.87 Kmph.
Brakes – Oil immersed disc brakes
Maximum Lifting capacity – 2500 kgf
Type – Power steering / Tilt steering option (Open operator station), Power steering / Tilt & Telescopic steering (Cab)
Type – Independent, 6 Splines
Standard – 540 @ 2100 ERPM
540 @ 1600 ERPM
Open operators station: Front – 12.4 x 24, 8 PR, Rear – 18.4 x 30, 12 PR
Cab: Front – 11.2 x 24, 8 PR, Rear – 16.9 x 30, 12 PR
Open operators station – 71 ltr & Cab- 82 ltr
85 Ah, 12 V battery, Cold charging Amphere – 800 CCA
60 Amp, alternator
12V, 2,5 Kv starter motor
Total weight – 2WD – 2450kgs . 4WD – 2700 kgs
Wheel base – 2050 mm
Overall length – 3678 mm
Overall Width – 1982 mm
Ground clearance– 2WD : 520 mm 4WD : 425 mm
